Autocad command: Autocad 3D commands and autocad 2d commands list is a comprehensive list of all the commands that can be used in AutoCAD. It includes commands for drawing, editing, measuring, and annotating objects. The Autocad command list is organized by category, such as 2D Drawing, 3D Modeling, and Object Properties. Each command has a brief description and a keyboard shortcut.
The AutoCAD command list is a valuable resource for anyone who uses AutoCAD. It can be used to learn new commands, find the shortcut for a command that you know, or to troubleshoot problems. The autocad command list can be accessed from the Help menu in AutoCAD. You can also refer check naviswork and E3d commands
Autocad is used in almost every engineering company like, Civil engineering, Electrical engineering, Mechanical engineering, Chemical engineering, Power engineering, Oil and Gas industries.
autocad command pdf
Autocad command list:- Autocad 2D commands and Autocad 3d commands
Line command: This command is used to draw lines in AutoCAD by writing in the AutoCAD command box. Just write shortcut ‘L’ in command prompt. Give distance the line will appear in AutoCAD.
Circle Command: To draw a circle write shortcut ‘C’ in command prompt. There are options there under circle command 2P, 3P, TTR options for drawing the circle.
Polylines (Pl): To draw multiple lines/Arc in AutoCAD used Polylines.
Arc (A): To draw arc used arc command. There are six type of Arc s in AutoCAD used as per requirement on drawings
Extend (ex): To extend existing Lines on drawings used extend command.
Trim (tr): To delete extend line at particular point used trim command.
Stretch (s): To increase the size of object.
Rectangle (Rec): To create a rectangle in AutoCAD used AutoCAD Rectangle command.
Polygon (Pol): To draw Pentagon, hexagon, Octagon used Polygon command.
Erase (E): To delete and object from drawings used erase command.
Dimensions (Dim): to give dimension to drawings used Dim command.
Match property: To make same colour/ style of previous object to new object used Match command.
Change properly (CH): If you want to increase /decrease /colour /layer of object used Change property command.
Hatch (H): For hatching object/fill solid/ colour/ material symbol used hatch command
Rotate (Ro): Rotate to line / object to any direction weather it clockwise or antic lock wise uses rotate command.
Move (M): Move the line/object from one place to another place in drawing used Move command.
Copy (Co): To copy similar line/object used copy command.
Mirror: If line /object required same size and in opposite direction used mirror command.
Array: This command used to copy object in horizontal direction as well as circular direction with specific c distance.
Explode: To break the assembly of objects like rectangle is one object use explode command to four different lines for rectangle.
Offset: To copy line /object at required distance
Text (T): To place a text in drawings used text command.
AutoCAD 3D Commands
Extrusion (Ext): To give the height of object used Extrusion command.
Subtractions (sub): Reduce the 3D solids from one solid to another solid. Example door from the wall.
Fillet (F): To round the edge of object used fillet command. Chamfer (CH): To give any angle to edge of object /surface used chamfer command.
Union: To combine 3D solid used union command.
Intersect: To create 3d solid by interesting of two object. Shell: Convert 3D Solid in to hollow shell of required wall thinness used shell command.
Autocad command line
The line command in AutoCAD is used to create straight line segments. It is a very versatile command that can be used to create different types of lines, depending on the desired start point, end point, and length.
Here are the steps on how to use the line command in AutoCAD:
- Enter line at the command prompt or press L as a shortcut.
- Specify the start point of the line.
- Specify the end point of the line.
- Press Enter to finish the line command.
How to use the stretch command in AutoCAD
- Enter stretch at the command prompt or press S as a shortcut.
- Select the objects you want to stretch by using a crossing or crossing polygon window.
- At the Specify base point: prompt, specify a point on the object that you want to use as the base point for the stretch.
- Drag the objects to the desired location.
- Press Enter to finish the stretch command.
How to use fillet command in autocad
The fillet command in AutoCAD is used to create rounded corners between two objects. It is a very versatile command that can be used to create different types of fillets, depending on the desired radius and the type of objects being filleted.
Here are the steps on how to use the fillet command in AutoCAD
- Enter fillet at the command prompt or press F as a shortcut.
- Select the first object.
- Type R or Radius and enter the radius of the fillet.
- Select the second object.
- Press Enter to finish the fillet command.
How to use array command in autocad
The array command in AutoCAD is used to create multiple copies of an object in a regular pattern. There are three types of arrays that can be created with the array command: rectangular arrays, polar arrays, and path arrays.
Rectangular arrays are created by specifying the number of rows and columns of copies that you want to create. The copies are arranged in a rectangular pattern, with the same spacing between each copy.
Polar arrays are created by specifying the number of copies that you want to create, the angle between each copy, and the center point of the array. The copies are arranged in a circular pattern, with the same spacing between each copy.
Path arrays are created by specifying the path that you want the copies to follow. The copies are arranged along the path, with the same spacing between each copy.
Here are the steps on how to use the array command in AutoCAD
- Enter array at the command prompt or press AR as a shortcut.
- Select the object that you want to array.
- Select the type of array that you want to create.
- Specify the parameters for the array.
- Press Enter to finish the array command.
How to show command bar in autocad
There are three ways to show the command bar in AutoCAD:
Keyboard shortcut: Press Ctrl+9.
Command: Type COMMANDLINE at the command prompt and press Enter.
- User Interface:
- Click on the Customize button in the Quick Access Toolbar.
- Select the User Interface tab.
- In the Palettes section, expand the Command Line item.
- Make sure that the Show checkbox is selected.
- Click on the OK button.
autocad command list
3DARRAY – Creates a 3D array of objects.
3DALIGN – Aligns 3D objects.
3DCLIP – Clips 3D objects.
3DCOORDINATES – Displays the current 3D coordinates.
3DDISTANCE – Calculates the distance between two points in 3D space.
3DDONUT – Creates a filled donut shape.
3DFACE – Creates a 3D face.
3DFILL – Fills a 3D object with a solid color.
3DFORMULA – Calculates a 3D formula.
3DINTERSECTION – Calculates the intersection of two 3D objects.
3DLINE – Creates a 3D line segment.
3DMESH – Creates a 3D mesh object.
3DMOVE – Moves 3D objects.
3DPAN – Pans the 3D view.
3DPOLYGON – Creates a 3D polygon.
3DPRINT – Prints a 3D model.
3DPROPERTIES – Displays the properties of a 3D object.
3DROTATE – Rotates 3D objects.
3DSCALE – Scales 3D objects.
3DSECTION – Creates a 3D section view.
3DSIN – Calculates the sine of a 3D angle.
3DSOLID – Creates a 3D solid object.
3DSURFACE – Creates a 3D surface object.
3DSWEEP – Creates a 3D swept object.
3DTEXT – Creates 3D text.
3DVIEW – Creates a 3D view.
3DWALK – Walks through a 3D model.
3DWIREFRAME – Displays a 3D object as a wireframe.
A – Adds a leader to an object.
ADDLEADER – Adds a leader to an object.
ALIGN – Aligns two objects.
ARRAY – Creates an array of objects.
BASE – Sets the base point for subsequent drawing
operations.
BEAD – Creates a bead object.
BLOCK – Creates a block definition.
BREAK – Breaks an object into two or more pieces.
BTEXT – Creates a block of text.
C – Copies an object.
CEILING – Rounds an object up to the nearest integer.
CHANGE – Changes the properties of an object.
CHPROP – Changes the properties of an object.
CIRCLE – Creates a circle.
CLIMATE – Sets the climate for a drawing.
CLOSE – Closes the current drawing.
COLOR – Sets the color of an object.
COPY – Copies an object.
CP – Copies and pastes an object.
CPOLY – Creates a complex polyline.
CREATELAYER – Creates a new layer.
DIM – Creates dimensions.
DIMALIGNED – Creates aligned dimensions.
DIMANGULAR – Creates angular dimensions.
DIMBASELINE – Creates baseline dimensions.
DIMCENTER – Creates center marks and dimensions.
DIMDIAMETER – Creates diameter dimensions.
DIMEDIT – Edits dimensions.
DIMLINEAR – Creates linear dimensions.
DIMORDINATE – Creates ordinate dimensions.
DIMRADIUS – Creates radius dimensions.
DIMSTYLE – Sets the dimension style.
DIMTEDIT – Edits T-values in dimensions.
DIVIDE – Divides an object into a specified number of segments.
DONUT – Creates a filled donut shape.
DRAG – Starts a drag operation.
DTEXT – Creates a text object.
EDIT – Edits an object.
ELLIPSE – Creates an ellipse.
EXPLODE – Explodes a compound object into its component objects.
EXTEND – Extends an object to another object.
EXTRUDE – Extrudes an object along a path.
FILL – Fills an object with a solid color.
FILTER – Filters objects based on their properties.
HATCH – Creates a hatch pattern.
INSERT – Inserts a block or drawing into the current drawing.
INTERSECT – Calculates the intersection of two objects.
LAYER – Creates, modifies, and deletes layers.
LINE – Creates a straight line segment.
LIST – Lists the properties of an object.
MEASURE – Creates a measure between two points.
MEASUREGEOM – Creates a measure between two points and displays the geometric properties of the measure.
MLINE – Creates a multiline object.
MOVE – Moves an object to a new location.
OFFSET – Creates a copy of an object at a specified distance.
PAN – Pans the current view.
PEDIT – Edits a polyline object.
PLINE – Creates a polyline object.
POINT – Creates a point object.
PROPERTIES – Displays the properties of an object.
PURGE – Removes unused objects from the drawing.
REDRAW – Redraws the current view.
REDRAWALL – Redraws all views.
REGEN – Regenerates the current view.
REGENALL – Regenerates all views.
REORDER – Changes the order of objects in a layer.
ROTATE – Rotates an object around a base point.
SAVE – Saves the current drawing.
SCALE – Scales an object by a specified factor.
SCRIPT – Executes a script file.
SELECT – Selects objects.
SETVAR – Sets a system variable.
SKETCH – Creates a sketch object.
SOLID – Creates a solid object.
SPACECLAIM – Performs Boolean operations on solid objects.
SPLINE – Creates a spline object.
STRETCH – Stretches an object to a new size and shape.
STYLE – Sets the current text style.
TABLET – Configures the tablet.
TEXT – Creates a text object.
TRIM – Trims an object to another object.
UNDEFINE – Undefines an object.
UNGROUP – Ungroups a group of objects.
UNITS – Sets the drawing units.
VIEW – Creates, modifies, and saves views.
VPOINT – Sets the viewpoint for the current view.
WBLOCK – Creates a block from selected objects.
XLINE – Creates an xline object.
ZOOM – Zooms the current view.
ZOOM – Zooms the current view.
ZOOMALL – Zooms the current view to display all objects.
ZOOMEXTENTS – Zooms the current view to display the extents of all objects.
ZOOMIN – Zooms the current view in.
ZOOMOUT – Zooms the current view ou
